MIL-DTL-85052B
Sample for qualification test
Specification MIL-DTL-85052 Clamp, Loop, Cushion
Specification sheet number
Manufacturers part number
Name of Manufacturer and Contractor And Government Entity (CAGE) Code
Submitted (date) and reference letter authorizing the test
4.3 Conformance inspection. Conformance inspection shall consist of the tests and
inspections specified in table II, conducted in accordance with 4.3.2.
4.3.1 Parts in inspection lot. Parts in an inspection lot shall consist of clamp assemblies
or elastomeric cushion molded products. These parts are produced under essentially the same
manufacturing conditions and presented for inspection at the same time.
4.3.1.1 Inspection lot for examination of product and clamp band hardness. An
inspection lot shall consist of clamp assemblies (elastomeric cushion and metallic band) for a
particular size, and material produced under essentially the same manufacturing conditions and
presented for inspection at the same time. Examination shall be conducted in accordance with
table II requirements.
TABLE II. Conformance inspection.
Examination and Tests
Requirement
Test
Inspection Level
Paragraph
Paragraph
ANSI/ASQ-Z1.4 1/
Examination of product
3.4
4.4.2
I
Clamp band hardness
3.5.2.1
4.3.3
S1
Cushion tensile
3.5.1.1
4.4.3.1
S1
Cushion elongation
3.5.1.1
4.4.3.1
S1
Ozone resistance
3.5.3.3
4.4.4.3
S1
1/ AQL shall be as specified in the contract (see 6.2) or by the qualifying activity.
4.3.1.2 Inspection lot for cushion tensile, cushion elongation, and ozone resistance. An
inspection lot shall consist of elastomeric products molded, extruded, and cured under essentially
the same conditions from the same batch of raw elastomer. Some mechanical processing may be
performed on the elastomeric product after inspection to prepare them for assembly onto clamp
bands. Cushions extruded and cured shall be considered separately from cushions molded and
cured for purposes of lot identification. The lot of elastomeric product shall be traceable to
clamp assemblies for quality reporting and certification. Examination shall be conducted in
accordance with table II requirements.
4.3.2 Sampling. A random sample shall be selected from each inspection lot in
accordance with ANSI/ASQ-Z1.4. The inspection level shall be as specified in table II. Cushion
material test specimens shall be cut from clamp cushions and shall be of sufficient size to be
tested in accordance with the test methods specified in the applicable specification sheet.
8
