MIL-DTL-85052B
1/ If MIL-DTL-85052/4 clamp supports are used, the maximum tube overhang shall be
0.5 tube. This clamp support can be detrimental if the clamp is not fully supported.
FIGURE 6. Recommended mounting of clamp at very high vibration areas.
6.5 Qualification. With respect to products requiring qualification, awards will be made
only for products which are, at the time of award of contract, qualified for inclusion in Qualified
Products List QPL No. 85052 whether or not such products have actually been so listed by that
date. The attention of the contractors is called to these requirements, and manufacturers are
urged to arrange to have the products that they propose to offer to the Federal Government tested
for qualification in order that they may be eligible to be awarded contracts or orders for the
products covered by this specification. Information pertaining to qualification of products may
be obtained from the Commander, Naval Air Systems Command, Code 4.3.5.2, Building 2187,
Room 3320C3, 48110 Shaw Road, Patuxent River, MD 20670 or email james.magno@navy.mil.
6.6 Acceptance Quality Limits (AQL) for quality conformance inspection. For
conformance inspection in Table II, 1.0 percent AQL per ANSI/ASQ-Z1.4 was used in the
previous revision for Clamp band hardness, Cushion tensile, Cushion elongation, and Ozone
resistance with inspection level S1.
Test requirements
Inspection Level
AQL
ANSI/ASQ-Z1.4
In percent
Clamp band hardness
S1
1.0
Cushion tensile
S1
1.0
Cushion elongation
S1
1.0
Ozone resistance
S1
1.0
18
