MIL-DTL-85052B
TABLE III. Classification of defects (qualification inspection).
ANSI/ASQ-Z1.4,
Test
Inspection Level I
Major
Minor
1/
Examination of product (see 4.4.2)
1/
A. Dimensions (see applicable specification sheet)
1. Clamp cushion
X
-
a. Material thickness
X
-
b. Inside width
X
-
c. Color (see applicable specification sheet)
2. Clamp band
X
-
a. Material thickness
X
-
b. Width
-
X
c. Bolt hole diameter
-
X
d. Edge de-burring
3. Clamp assembly
-
X
a. Loop diameter D (see 4.4.4.1)
-
X
b. Centerline of loop to centerline of bolt hole E
-
X
B. Workmanship and marking
1/ AQL for major and minor shall be as specified in the contract (see 6.2) or by the qualifying
activity.
4.4.3.3.1 Flammability preconditioning. All specimens shall be preconditioned in an
o
oven at 70 + 5 F and 50 + 5 percent relative humidity for a period of 24 hours prior to testing.
Clamps used for the vertical burn test shall be uncurled until straight before being placed in the
preconditioning chamber. The cushion shall not be removed from the clamp band.
10
