A-A-1193A
Dimensions and load capacity of hangers shall be as specified in Table I below.
Table I.
|
SIZE |
Surface area (square inches max.) |
Load Capacity (lbs.-min.) |
|
A |
10.0 |
2.5 |
|
B |
25.0 |
4.0 |
|
C |
35.0 |
8.0 |
|
D |
50.0 |
16.0 |
1/ Each size hanger, when in contract with a clean smooth metallic (ferrous) surface in a vertical plane at 25o + 5o C, shall be capable of supporting the load specified above for two minutes without any measurable downward vertical movement of the hanger.
