MIL-DTL-85052/3C
TABLE I. Clamp dimensions - Continued. 8/
E 7/
J 5/
R
T
Y 5/
Dash
C
D 6/
Dia
+ .032
(Ref)
+ .010
(Ref)
No.
(Ref)
14
.580
.875
.898
.032
+ .002
.368
.256
15
.611
.938
.929
16
.642
1.000
.960
17
.681
1.062
1.001
18
.712
1.125
1.032
.125
19
.744
1.188
1.064
.262
.040
.370
20
.775
1.250
1.095
+ .003
21
.806
1.312
1.126
22
.838
1.375
1.158
23
.869
1.438
1.189
24
.900
1.500
1.220
5/ See figure 1, note
6/ See figure 1, note
7/ See figure 1, note
8/ See figure 1, note 8
REQUIREMENTS:
MARKING
Band. The complete standard part number and manufacture's name, trademark, or
Contractor And Government Entity (CAGE) code shall be impression stamped on the band in an
area not covered by the cushion. All marking shall be above tube theoretical centerline
(see figure 1). Due to space limitations, clamp bands of - 2, - 3, - 4 sizes may be marked with the
manufacturer's identification, the size, and the specification sheet number.
Cushion. None
MATERIALS:
Metal Band. 17-7PH corrosion resistant steel conforming to SAE-AMS5528 or
SAE-AMS5529, annealed, stress relieved, and heat-treated to TH1100 condition in accordance
with SAE-AMS-H-6875 after forming.
Cushion. Fabric reinforced silicone rubber, 65-75 durometer, on unreinforced
material, color light blue conforming to SAE-ARP1527 with additional requirements specified
herein. The fabric reinforcing material shall be molded into the band side of the clamp cushion
o
at a 45 angle shown below.
3
