A-A-55620C
TABLE I. DASH NUMBERS AND DIMENSIONS
DASH
STRAP
A
C
E
F
H
NO.
WIDTH
(REF)
-3S
1.00
1.062
1.312
.090
.135
.312
-4S
1.25
1.312
1.625
.090
.166
.312
-5S
1.50
1.625
1.875
.090
.188
.312
-7S
2.00
2.125
2.375
.090
.188
.312
-9S
1.00
1.062
1.265
.050
.125
.188
2.2 Material: Loops shall be made of cold rolled carbon steel strips per ASTM A109/A109M, No 3 quarter
hard temper.
2.3 Finish: Steel loops shall be given a phosphate treated zinc plate, conforming to Type IV, Fe/Zn 12
per ASTM B633, followed by enamel in accordance with Master Painters Institute Reference # 94, Exterior
Alkyd, Semi Gloss, MPI Gloss Level 5, color black.
2.4 Tolerance: xxx ±.005
2.5 Workmanship. The loops furnished shall be free from imperfections which may impair durability or
serviceability.
3. REGULATROY REQUIREMENTS.
3.1 The offerer/contractor is encouraged to use recovered materials to the maximum extent practicable, in
accordance with paragraph 23.403 of the Federal Acquisition Regulations (FAR).
4. PRODUCT CONFORMANCE PROVISIONS.
4.1 Product conformance. The products provided shall meet the salient characteristics of this commercial
item description, conform to the producer's own drawings, specifications, standards, and the quality
assurance practices, and be the same product offered for sale in the commercial market. The government
reserves the right to require proof of such conformance.
5. PACKAGING.
5.1 Preservation, packing and marking shall be as specified in the contract or order.
6. NOTES.
6.1 Unless otherwise specified, all dimensions are in inches.
6.2 Unless otherwise specified in the contract or purchase order, packaging shall be in accordance with
ASTM D3951.
6.3 The following part or identification numbering procedure is for government purposes and does not
constitute a requirement for the contractor. The Part Identification Number (PIN) shall consist of the basic
commercial item description number followed by a dash number from Table I.
2
