INCH-POUND
A-A-55595B
27 August 2010
SUPERSEDING
A-A-55595A
21 May 2002
COMMERCIAL ITEM DESCRIPTION
HINGE, BUTT, CONTINUOUS (PIANO)
.090 THICKNESS, .250 & .375 PIN DIA
The General Services Administration has authorized the use of this
Commercial Item Description for all Federal Agencies.
1. SCOPE. This Commercial Item Description (CID) covers commercial and industrial quality, continuous
butt piano hinges suitable for use on cases, chests, and any other adaptable surface.
2.
SALIENT CHARACTERISTICS.
2.1 Butt hinges and pin hinge furnished under this CID shall conform to the dimensions as specified in Table I
and Figure 1 below.
G ((SEENOTTE .6.)3)
SEE NO E 6 3
L
275 MIN
A
F
B
OPENING
.040 MAX
D
.090 ±.005
P
IMPRESS PART IDENTIFICATION NUMBER AT A MAXIMUM OF 5 INCH INTERVALS
FIGURE 1. HINGE.
TABLE I. DASH NUMBERS AND DIMENSIONS
WIDTH
KNUCKLE
PITCH
KNUCKLE
PIN
STOCK
LENGTH
LENGTH
DASH
A
B
G
.031
F
D 1/
L
No.
REF
P 2/
.03
1.500
3.000
11
84.00
1.750
3.500
12
.250 .002
SEE SAL.
.255 +.007
1.998 +.000
4.000 +.015
2.000
4.000
13
CHAR. 2.6
-.001
-.015
-.003
2.500
5.000
14
2.000
4.000
15
.375 .002
2.500
5.000
16
.380 +.007
3.000
6.000
17
-.001
1/ SEE SAL. CHAR. 2.4
2/ SEE SAL. CHAR. 2.5
Comments, suggestions, or questions on this document should be addressed to Defense Supply Center
Philadelphia, ATTN: DSCP-NASA, 700 Robbins Avenue., Philadelphia, PA 19111-5096 or e-mail to
dscpg&ispecomments@dla.mil. Since contact information can change, you may want to verify the currency of
this address information using the ASSIST Online database at https://assist.daps.dla.mil.
ASMC N/A
FSC 5340
